Setting & Locking - BMW
345
BMW
A
NEW
Petrol 2.5, 3.0 N51/N52/N52K/N53/N54
Chain
Also see Associated Tool -
VSE6156
(see page 344).
Model No.
VSE6111
A
N52/N52K:
B25A
B25A/O1
B25AE
B25AF
N52/N52K:
B25BE
B2501
B2502
B25U1
N52/N52K:
B30/O2
B30A
B30A/O1
B30AE
N52/N52K:
B30AF
B30O2
B30U1
N53/N54:
B25A
B30A
B30A/AA
B30A/O0
N53/N54:
B30A/T0
B30O0
B30TD
B30UO
Engine Codes:
Applications:
125i E88 (07-13)
128i E82/88 (07-08)
130i E81/87 (05-12)
135i/S E82 (07-11)
M Coupe (11-12)
323i E90/91/92/93 (04-11)
325i E90/91/92/93 (05-13)
328i E90/91/92/93 (04-08)
330i E90/91/92/93 (04-14)
335i E90/91/92/93 (05-11)
523i/Li E60/61/F10/11 (04-11)
525i E60/61 (04-10)
528i E60/61/F10/11 (06-11)
530i E60/61/F10/11 (04-13)
535i E60/61 (06-08)
630i E63/64 (04-11)
730i E65/66 F01/02/04 (04-11)
740i F01/02/04 (08-12)
X1 E84 X-Drive 20i (11-14)
X1 E84 S-Drive 20i (11-14)
X1 E84 X-Drive 28i (11-14)
X1 E84 3.0 xDrive 25i E84 (10-11)
X1 E84 xDrive 28i (09-11)
X3 F25 20i (11-14)
X3 F25 20i (11-14)
X3 E83 2.5Si (06-10)
X3 E83 3.0i/Si (06-10)
X3 F25 3.0 xDrive 28i (11-13)
X5 E70 3.0Si/xDrive 30i (06-10)
X6 E71/72 3.0 xDrive 35i (08-10)
Z4 E85/86 2.5i/Si (05-09)
Z4 E85/86 3.0i/Si (05-09)
Z4 E89 2.5 sDrive 23i (09-11)
Z4 E89 3.0 sDrive 30i (09-11)
Z4 E89 3.0 sDrive 35i/is (09-13)
Camshaft/Carrier Bracket Remover
& Installer Tool Kit
Chain
Also see Associated Tool -
VSE5911A
(see page 344).
Model No.
VSE5926
B
B
NEW
BMW
Used in conjunction with Model No. VSE5911A Timing Kit - the kit provides
the specialist tools for removal and installation of camshafts and dismantling/
rebuilding camshaft carrier bracket/Valvetronic assembly. Essential tools for safe
removal of torsion springs.
Flywheel Holding Tool
Also see Associated Tools -
VSE5666
(see page 342),
VSE6121
(see page 342),
VSE5981
(see page 344),
VSE5911A
(see page 344),
VSE5926
(see above),
VSE6156
(see page 344),
VSE6111
(see top left),
VSE5665
(see page 356).
Model No.
VSE5660
C
C
NEW
Essential tool for holding the flywheel when releasing and tightening the vibration
damper central bolts on BMW M47T2, M57T2, M57TU, M67, N20, N26, N43,
N45, N45T, N46, N46T, N47, N51, N52, N53, N54 & Mini W17 diesel/petrol chain
drive engines. The tool can also be used to hold the flywheel when removing the
timing chain for cylinder head work.
Chain
BMW
Applications:
540i E60/61 (05-10)
545i E60/61 (03-06)
550i E60/61 (05-10)
645i E63/64 (03-06)
650i E63/64 (05-11)
735i E65/66 (02-05)
740i E65/66 (05-08)
745i E65/66 (02-05)
750i E65/66 (05-08)
760i E65/66 (02-08)
X5 E53 4.4 (03-07)
X5 E53/E70 4.8 (04-10)
Engine Codes:
N62/N62TU V8:
B36A
B40A
B44A
B48B
N73 V12:
B60A
Petrol 3.6, 4.0, 4.4, 4.8 V8
N62/N62TU + 6.0 V12 N73
Chain
BMW
E
Model No.
VSE6166
E
Petrol 3.0, 3.5, 4.0, 4.4, 4.6 M60/M62
Chain
Model No.
VSE5555
D
D
NEW
BMW
LAND ROVER
MORGAN
Applications:
BMW 5 Series:
530i E34 (93-95)
540i E34 (93-95)
535i E39 (96-98)
535i E39 with Vanos (97-03)
540i E39 (96-98)
540i E39 with Vanos (98-03)
BMW 7 Series:
730i E38 (92-96)
735i E38 (96-97)
735i E38 with Vanos (98-02)
740i E38 (92-98)
740i E38 with Vanos (99-01)
BMW 8 Series:
840i E31 (92-96)
840i E31 with Vanos (96-97)
BMW X Series:
X5 E53 (99-04)
Land Rover:
Range Rover (02-05)
Morgan:
Aero 8 (00-04)
Engine Codes:
3.0:
308S1
3.5:
358S1
358S2
4.0:
408S1
4.4:
448S1
448S2
Morgan M62
4.6:
468S1
