Setting & Locking - VAG
367
Model No.
VSE5953
G
Model No.
VSE5952
F
Diesel 1.2D, 1.4D, 1.9D, 2.0D TDi
Pumpe Duse & Common Rail - Camshaft
Sprocket Hub Remover/Installer Set
Belt
Diesel 2.0D TDi Pumpe Duse
Balance Shaft Locking Set
Belt
Essential tool required when removing the cylinder head/camshafts on VAG
Pumpe Duse and Common Rail diesel engines. Set comprises camshaft sprocket
hub holding tool and hub remover.
Special tools required during removal/installation of the balance shaft on certain
VAG 2.0D Pumpe Duse diesel engines. Set comprises balance shaft locking tool
and chain tensioner locking pin. These engines are a belt drive with the balance
shaft driven separately by a chain. Please refer to website for full applications.
Applications:
Audi:
A4 (04-08)
A6 (05-08)
Engine Codes:
BLB
BNA
BRD
BRE
BRF
BVA
BVF
BVG
VAG
VAG
Also see Associated Tool -
VSE5951
Setting/Locking Kit (see page 366).
Also see Associated Tool -
VSE5951
Setting/Locking Kit (see page 366).
F
G
Applications:
VW:
Crafter (06-12)
LT (96-06)
Transporter (90-03)
Engine
Codes:
2.4D:
AAB
AJA
2.5D SDI:
AGX
2.5D TDi:
ACV
AHD
AHY
AJT
ANJ
APA
AUF
AVR
AXG
AXL
AYC
AYY
BBE
BBF
2.5D TDi CR:
BJJ
BJK
BJL
BJM
2.5D
BlueTDi CR:
CEBA
CEBB
CECA
CECB
Applications:
Audi:
A4 (97-09)
A6 (97-05)
A6 Allroad (00-05)
A8 (97-02)
Skoda:
Superb (02-08)
VW:
Passat (98-05)
Engine Codes:
AFB
AKE
AKN
AYM
BAU
BCZ
BDG
BDH
BFC
Diesel 2.4D, 2.5D SDi/TDi/TDi CR
Belt
Diesel 2.5D TDi V6
Belt
Also see Associated Tool -
VSE5959
(see below).
Also see Associated Tools -
VSE2351
(above),
VSE2354
&
VS4827
(page 371)
Camshaft Sprocket Remover
Belt
Applications:
VW:
Touareg (03-10)
Transporter (03-09)
Engine Codes:
2.5D TDi PD:
AXD
AXE
BAC
BLJ
BLK
BNZ
BPC
BPD
BPE
Diesel 2.5D TDi PD - Water Pump Removal Kit
Gear
VAG
VAG
VAG
A
B
C
E
Model No.
VSE2351
B
Model No.
VSE5959
C
Model No.
VSE5559
A
Model No.
VSE6000
E
Applications:
VW:
Touareg (03-10)
Transporter (03-09)
Engine Codes:
AXD
AXE
BAC
BLJ
BLK
BNZ
BPC
BPD
BPE
Diesel 2.5D TDi PD
Gear
Model No.
VSE6146
D
Also see Associated Tool -
VSE6000
(see right).
D
NEW
VAG
VAG
