422
Battery & Alternator Testers
A
Digital Battery Tester 12V
Model No.
BT101
A
Compact design digital tester suitable for professional
use. Utilises low current draw technology to evaluate
condition of SLI, VRLA, AGM and Gel batteries. Just
key in the battery rating from the top of the battery.
Simple, fast and accurate evaluation of battery
condition. Results displayed on LED control panel. No
internal battery and will test batteries with a residual
charge of just 7V.
Rated Battery Voltage:
12V
Rating Systems:
SAE, DIN, EN, IEC, CA
Test Range:
200-1200 CCA* (SAE) 7-15V
Minimum Power Requirement:
7V
*CCA - Cold Cranking Amps
B
Digital Battery & Alternator Tester 12V
Model No.
BT102
B
Compact design digital tester suitable for professional
use. Utilises low current draw technology to evaluate
condition of SLI, VRLA, AGM and Gel batteries and
charging systems. Just key in the battery rating from
the top of the battery. Simple, fast and accurate
evaluation of battery condition. Results displayed on
LED control panel. No internal battery and will test
batteries with a residual charge of just 7V. Can also
be used to evaluate the condition of the alternator and
charging circuitry of the vehicle.
Rated Battery Voltage:
12V Battery
12V Charging/Starting Systems
Rating Systems:
SAE, DIN, EN, IEC, CA
Test Range:
200-1200 CCA* (SAE), 7-15V
Minimum Power Requirement:
7V
*CCA - Cold Cranking Amps
C
Digital Battery Tester 12V
Model No.
BT2101
C
Fast and accurate assessment of battery condition,
even with the battery partially discharged. No heat,
no sparks and no misdiagnosis. Tests battery in
accordance with rated output based on SAE, DIN or
ENC2 criteria and displays results on LCD screen.
Handle battery faults on the trade counter, in service
reception or in workshop with confidence. Rugged
construction. Supplied with instruction manual.
Rated Battery Voltage:
12V
Rating Systems:
SAE, DIN, ENC2
Test Range:
200-1200 CCA* (SAE), 9-15V
Minimum Power Requirement:
9V
*CCA - Cold Cranking Amps
D
Digital Battery Tester 6/12V
Model No.
BT2001
D
Fast and accurate assessment of battery condition,
even with the battery partially discharged. No heat,
no sparks and no misdiagnosis. Tests battery in
accordance with rated output based on DIN, ENC1,
ENC2, IEC, JIS or SAE criteria and displays results
on LCD screen. Handle battery faults on the trade
counter, in service reception or in workshop, with
confidence. Rugged construction with protective
cover. Supplied with full instruction manual.
Rated Battery Voltage:
6/12V
Rating Systems:
DIN, ENC1, ENC2, IEC, JIS, SAE
Test Range:
40-2100 CCA* EN
40-2000 CCA* SAE
30-1500 CCA* IEC
25-1300 CCA* DIN
Minimum Power Requirement:
1V
*CCA - Cold Cranking Amps
E
Digital Battery & Alternator Tester 6/12/24V
Model No.
BT2002
E
Professional diagnosis of battery and alternator faults.
Test battery condition with as little as 1V of residual
charge. No heat, no sparks and no misdiagnosis.
Checks condition of starter - no complicated
connections or interpretation required. Analyse the
vehicle’s charging system at rest and under load to
determine condition of alternator. Connect and follow
the prompts on the LCD screen for straightforward
answers. Incorporates simple voltmeter for voltage
tests and additional system diagnostics. Rugged
construction with protective cover. Supplied with full
instruction manual.
Rated Battery Voltage:
6/12V
Charging System Capability:
6/12/24V**
Rating Systems:
SAE, DIN, EN, IEC
Test Range:
40-2100 CCA* EN
40-2000 CCA* SAE
30-1500 CCA* IEC
25-1300 CCA* DIN
Minimum Power Requirement:
1V
*CCA - Cold Cranking Amps. ** 24V Alternator Test only
E
SIMPLE TO USE
Connect to battery - tester reads
battery voltage.
Select battery type.
Input battery amperage.
Press
enter.
Battery condition is displayed
in full*.
* Not BT101 - BT102
