Engine Tools
437
B
OHC Valve Spring Compressor
Model No.
VS153
B
Suitable for most small and medium sized OHC engines
and also for general use on OHV and CVH engines.
Universal jaw with 60-155mm capacity and 160mm
throat depth. Parallel lift action with automatic lock.
A
OHV Valve Spring Compressor
Model No.
VS152
A
Suitable for most small and medium sized OHV
engines. Fully adjustable jaw with 75-165mm capacity
and 150mm throat depth. Parallel lift action with
automatic lock.
C
OHV Valve Spring Compressor
Model No.
VS168
C
Suitable for the replacement of valve springs and
valve stem oil seals without the need to remove the
cylinder head. Use in conjunction with Model No.
VS1601 compressed air adaptor. Adjustable handle,
claws and hooks allow use on most OHV engines.
Note: Not suitable for vehicles with deep-seated valves.
D
Multi-Valve Spring Compressor
Model No.
VS154
D
Suitable for use on multi-valve petrol and diesel engines with deep-seated valves. Suitable also for general use
on OHC, OHV and CVH engines. Universal jaw with 55-175mm capacity and 165mm throat depth. Reversible
jaw and adaptor. Twin cam action permits use from above or below valve.
E
OHV Valve Spring Compressor
Model No.
VS160
E
Permits valve springs and valve stem oil seals to be
replaced without the need to remove the cylinder head
when used in conjunction with Model No. VS1601
Compressed Air Adaptor. Reversible jaw adaptor and
automatic cam action lock to pre-set spring tension.
Suitable for use on a wide range of OHV, OHC and
CVH engines.
Note: Not suitable for engines with deep-seated valves.
F
Compressed Air Adaptor
Model No.
VS1601
F
Use with Model No's VS160 or VS168 to hold the valves
closed whilst spring is compressed. Spark plug adaptor
with M14 and M18 threaded fittings for car and light
commercial use. Valve assembly maintains cylinder
pressure when air supply is cut. Requires a 90-125psi
supply. Requires standard bayonet air line coupling (not
supplied).
G
Rocker Arm & Valve Compensator Tool
Model No.
VS151
G
Suitable for use on Vauxhall/Opel OHC engines.
Permits quick, on vehicle, removal of rocker arm and
valve play compensator. Mounts on camshaft housing.
Cast construction with knurled hex head fixing.
H
Valve Collet Installer/Remover
Model No.
VS1651
H
Spring loaded shaft and clips aid simple and secure
installation of valve spring collets. Quick and easy
retrieval of lost collets using magnetic tip. Suitable for
8, 16 and 24 valve engines. Ideal for use on heads
with recessed valves.
Length:
220mm
Valve Configuration:
8/16/24
I
CVH Valve Spring Compressor - Ford
Model No.
VS150
I
Permits valve stem seal and valve spring replacement
without the need to remove the cylinder head. Superior
cast design with radiused fulcrum for smooth spring
compression. Suitable for CVH Ford engines 1.3, 1.4
and 1.6 as fitted to Escort (inc. XR3i and RS Turbo),
Fiesta (inc. RS Turbo) and Orion.
J
Valve Stem Seal Pliers - Long Stem, 16/24v
Model No.
VS1671
J
Steel long stem aids removal and installation of valve
stem seals on 16 and 24 valve OHC engines. Serrated
tips aid grip. Especially suited to stubborn seals.
Type:
Straight Head
Length:
270mm
