Commercial Vehicle Tools
527
A
Wheel Removal Trolley Adjustable Width
500kg Capacity
Model No.
W508T
A
Suitable for changing wheels and tyres on the very
largest vehicles. Eight-position adjustable roller width
ranging from 440 to 780mm giving greater flexibility.
Load arms incorporate smooth roller action sleeves
allowing wheel to be rotated for lining up on studs.
Foot operated hydraulic mechanism with dead man’s
control release. Mounted on two castors and two
fixed wheels for stability and easy manoeuvrability.
Supplied with safety chain.
Maximum Lifting Capacity:
500kg
Minimum Lifting Height:
50mm
Maximum Lifting Height:
640mm
Width Between Rollers:
440, 496, 560, 610, 668,
724, 780mm
Roller Length:
620mm
C
Wheel & Tyre Handling Dolly 127kg Capacity
Model No.
TH002
C
Enables commercial sized wheels and tyres to be
removed/installed on hub studs.
Capacity:
127kg
Fork Centres:
535mm
Length:
1255mm
B
Heavy-Duty Rubber Wheel Chocks 16kg/Pair
Model No.
WC11
D
Two rubber wheel chocks. Prevents vehicle movement
when jacking or parking on an incline. Suitable for
heavy commercial vehicles and light aircraft. Chocks
supplied on rope for easy storage and removal from
underneath wheels.
Dimensions (H x L x W):
140 x 155 x 455mm
Weight Each:
8kg
E
Heavy-Duty 4.4kg Slide Hammer Kit 10pc
Model No.
DP90
E
Heavy-duty slide hammer with 4.4kg sliding weight.
For use on body panels and vehicle chassis. Supplied
with various attachments in tough storage carry-case.
Sliding Weight:
4.4kg(10lb)
Attachments:
Small & Large Flat Hooks, Small
& Large Right Angle Hooks, Straight Bar, Hook with
Chain, Self Tapping Screw, Taper Screw, Adaptor.
F
Wheel Chock with Bracket - HGV
Model No.
CV127
F
High-density plastic with anti-slip steel bar to ensure
that the vehicle will not move when being jacked or
parked on an incline. Steel chock bracket designed to
mount to wall or trailer.
Chock Dimensions (H x L x W):
225 x 475 x 200mm
Chock Weight:
1.7kg
Bracket Weight:
1.36kg
Wheel Removal Trolley Adjustable 1200kg Capacity
Model No.
W1200T
B
Eight adjustable rollers (4 each side) allow for easy
turning of large deep tread tyres. Extra-large jacking
handle and hydraulic foot pedal allows for one man
operation. Safety bar with composite guard goes
around wheel to ensure stability during transportation.
Locking mechanism allows rollers to be fixed at eight
preset positions. Mounted on two locking and two
non-locking castors for improved stability and easy
manoeuvrability. Ideal for use on agricultural and
commercial wheels and tyres.
Maximum Lifting Capacity:
1200kg
Minimum Wheel Ø:
1000mm
Maximum Wheel Ø:
2200mm
Roller Length:
490mm
Minimum Lifting Height:
0mm
Maximum Lifting Height:
760mm
Weight:
118kg
NEW
D
JACKING & LIFTING EQUIPMENT
For our full
range of
Jacking & Lifting
Equipment,
see pages
225 to 273.
