Wireless Security System
833
A
Wireless Security Starter Kit
Model No.
SWSKIT
A
Ideal for safeguarding your home or business. Supplied with smart panel control
hub, two door/window sensors, PIR motion sensor and wireless control fob, with
a range spanning up to 250mtr. The system is controlled by the control hub which
gathers information from wireless sensors which are easily installed in various
locations around the home or business. In addition the system can easily be
expanded, by adding Window Sensors, Garage Door Sensors and Wireless Bell
Box Alarms. The control hub is mains powered but can be fitted with a 9V Li-ion
rechargeable battery back up (not included) to prevent loss of protection during a
mains power cut. System features eight customisable zones with three operation
modes: Alarm, Alert and Home. Fitted with an integral 120dB siren. Also features
programmable entry/exit delay timers and password settings.
B
Wireless PIR Motion Sensor
Model No.
SWS01
B
PIR Motion Sensor for use in conjunction with Model
No. SWSKIT Starter Kit. Can easily be integrated
to increase the level of protection of your home or
business. Sensor is designed to monitor motion and,
when armed, will send a signal to the control hub
alerting the system of a possible intruder. Features
power saving 3 minute motion lockout after each
detection, 120° detection and multi-directional
mounting bracket. Supplied with fixing kit. Powered by
1 x 9V alkaline battery (not included).
Dimensions (W x D x H):
66 x 38 x 124mm
Battery:
1 x 9V Alkaline (not included)
C
Wireless Door/Window Sensor
Model No.
SWS02
C
Door/Window Sensor for use in conjunction with
Model No. SWSKIT Starter Kit. Can easily be
integrated to increase the level of protection of your
home or business. This sensor attaches to the frame
of a window or door and, when armed, will send a
wireless signal to the control hub, alerting the system
of a possible intruder. Features low battery warning
notification and supplied with fixing kit. Powered by
2 x AAA batteries (not included).
Dimensions (W x D x H):
40 x 16 x 88mm
Battery:
2 x AAA Alkaline (not included)
D
Wireless Garage Door Sensor
Model No.
SWS03
D
Garage Door Sensor for use in conjunction with Model
No. SWSKIT Starter Kit. Can easily be integrated
to increase the level of protection of your home or
business. This sensor attaches to the inside frame of
a garage door and, when armed, will send a wireless
signal to the control hub alerting the system of a
possible intruder. Ideal for use on up and over style
doors. Features low battery warning. Powered by
2 x AAA batteries (not included). Supplied with
fixing kit.
Dimensions (W x D x H):
40 x 16 x 88mm
Battery:
2 x AAA Alkaline (not included)
Contents:
1 x Smart Panel Control Hub, 1 x Key Fob, 2 x Door/Window Sensors,
1 x Motion Sensor with Directional Mounting Bracket and Mounting Kit
Main Panel (W x D x H):
152 x 32 x 100mm
Door/Window Sensors (W x D x H):
40 x 16 x 88mm
PIR Motion Sensor (W x D x H):
66 x 38 x 124mm
Supply/Battery:
Base Unit:
230V, 1 x 9V Li-ion Rechargeable Back-Up (not included)
Door/Window Sensors:
2 x AAA Alkaline (not included)
Remote Control:
1 x 12V Alkaline (not included)
Alarm:
120dB
SWS01 Monitors movement around a room at 120°
angle.
SWS02 Fits to any window/door frame monitoring
possible forced entries.
SWS03 Ideal for ‘up and over’ style garage doors,
alerting the system of an unauthorised entry.
C
B
D
Home Mode
Alert Mode
Alarm Mode
