228
Trolley Jacks
Trolley Jack 3tonne
Model No.
3000CXD
C
Single-piece hydraulic unit with heavy base design.
Integral cog-type release mechanism and long
two-piece handle. Heavy-duty castors and extra large
saddle design ease positioning under vehicle. Fitted
with safety overload valve and pump-through valve to
prevent handle locking at maximum ram extension.
Ideal for loaded vans up to 3.5tonne GVW.
Optional Rubber Jack Pad:
3000CXD/JP
D
Trolley Jack 3tonne
Model No.
3010CX
D
Single-piece hydraulic unit with heavy chassis design.
Integral American cog-type release mechanism and
long two-piece handle. Heavy-duty castors and large
saddle design ease positioning under vehicle. Fitted
with safety overload valve and pump-through valve to
prevent handle locking at maximum ram extension.
Ideal for loaded vans up to 3.5tonne GVW.
E
Trolley Jack 3tonne Super Rocket Lift
Model No.
3012CXD
E
Single-piece hydraulic unit with heavy base design
and large jacking saddle. Twin piston Super Rocket
Lift feature brings lifting arm straight into contact with
the jacking point in 1-2 strokes. Universal joint release
mechanism allows safer, more controlled lowering
of the jack. Fitted with safety overload valve and
pump-through valve to prevent handle locking at
maximum ram extension. Suitable for loaded vans up
to 3.5tonne GVW.
Optional Rubber Jack Pad:
3000CXD/JP
B
Trolley Jack 2tonne
Model No.
1250CX
B
Professional and fully portable 2tonne trolley jack.
Features American cog-type integral handle release
mechanism with long two-piece handle. Short chassis
design with heavy-duty castors to assist in positioning
the jack under the load. Fitted with safety overload
valve. Compact design makes this jack equally
suitable for workshop or recovery vehicle use.
Model No:
1250CX
3000CXD
3010CX
3012CXD
3015CXD
Capacity:
2tonne
3tonne
3tonne
3tonne
3tonne
Minimum Saddle Height:
150mm
133mm
133mm
145mm
132mm
Maximum Saddle Height:
495mm
515mm
515mm
520mm
472mm
Maximum Chassis Height:
165mm
154mm
154mm
160mm
158mm
Length:
580mm
661mm
661mm
670mm
620mm
Weight:
28kg
36.8kg
36.8kg
39.5kg
31kg
B
C
D
E
F
Combination Trolley Jack 2tonne
Model No.
2000CJX
A
Single-piece hydraulic unit with heavy base design. Integral cog-type release mechanism and long two-piece
handle. Heavy-duty castors are fitted with brakes so this jack can be used as a quad/bike lift as well as a standard
jack. Large saddle design to ease positioning under vehicle. Removable saddle to improve stability and safety
when lifting motorcycles and quadbikes. Additional rubber gripped padding on the lifting plates increases stability.
Features solid stainless steel locking pin to lock jack in raised position for prolonged use and reduce pressure on the
hydraulics when at maximum height. Fitted with safety overload valve and pump through valve to prevent handle
locking at maximum ram extension.
Capacity:
2tonne
Minimum Height (with Saddle):
160mm
Maximum Height (with Saddle):
445mm
Minimum Height (without Saddle):
150mm
Maximum Height (without Saddle):
435mm
Maximum Chassis Height:
165mm
Length:
570mm
Weight:
37kg
Suitable for lifting cars as a
traditional Trolley Jack.
Suitable for lifting Motorbikes.
Locking Pin.
Suitable for lifting Quadbikes.
C
Trolley Jack 3tonne Super Rocket Lift
Model No.
3015CXD
F
Single-piece hydraulic unit with heavy base design and
large jacking saddle. Twin piston Super Rocket Lift feature
brings lifting arm straight into contact with the jacking point
in 1-2 strokes. Universal joint release mechanism allows
safer, more controlled lowering of the jack. Fitted with
safety overload valve and pump-through valve to prevent
handle locking at maximum ram extension.
F
NEW
A
Safety
System
