230
Trolley Jacks
Trolley Jack 3tonne Super Rocket Lift
Model No.
3003CXQ
A
Single-piece hydraulic unit with heavy base design.
Integral cog-type release mechanism and two-piece
handle. Super Rocket Lift feature brings lifting arm
straight into contact with jacking point with a single
pump of the handle. Integral saddle pad provides
protection for the jacking point. Heavy-duty castors
and 55mm wide front wheels for even load distribution.
Replacement Rubber Jack Pad:
SSP223
Trolley Jack 3.2tonne Super Rocket Lift
with PU Wheels
Model No.
3200CXQP
B
Polyurethane wheels for smoother manoeuvrability
and prevents damage to workshop floor. Single
piece hydraulic unit with heavy base design. Integral
cog-type release mechanism and two-piece handle
which is fitted with protective sleeve to help prevent
damage to vehicle bodywork during use. Super
Rocket Lift feature brings lifting arm straight into
contact with jacking point with a single pump of the
handle. Integral saddle pad provides protection for the
jacking point. Heavy-duty castor wheels and 55mm
wide front wheels for even load distribution.
Replacement Rubber Jack Pad:
SSP223
Trolley Jack 2tonne Low Entry
Super Rocket Lift
Model No.
2000LEQ
C
Low entry to suit vehicles with low ground clearance.
One-piece hydraulic unit. Two-piece handle with
integral cog-type release mechanism. Super Rocket
Lift feature brings lifting arm into contact with jacking
point with two or less strokes of the handle. Integral
saddle pad provides protection for the jacking point.
Heavy-duty swivel castor and Ø72mm x 44mm wide
front wheels.
Replacement Rubber Jack Pad:
SSP223
Trolley Jack 2.5tonne Low Entry
Model No.
2500LE
D
Heavy-duty chassis with strengthening flanges along
the top edge for extra torsional rigidity under load.
Profiled lifting arm allows low clearance height of just
85mm making this unit suitable for sports and custom
cars. Fitted with heavy-duty one-piece hydraulic unit
with pump-through action preventing handle locking
at maximum ram extension. White saddle aids
positioning under vehicle and safety valve prevents
overloading. Integral release mechanism prevents
inadvertent lowering of saddle.
E
Trolley Jack 3tonne Heavy-Duty Low Entry
Model No.
3001LE
E
Heavy-duty chassis with strengthening flanges along
the top edge for extra torsional rigidity under load.
Profiled lifting arm allows low clearance height of just
95mm making this unit suitable for sports and custom
cars. Fitted with heavy-duty one-piece hydraulic unit
with pump-through action preventing handle locking
at maximum ram extension. Large sized white saddle
aids positioning under vehicle and safety valve
prevents overloading. Integral release mechanism
prevents inadvertent lowering of saddle.
F
EVA Jack Handle Sleeve 400mm x 30mm ID
Model No.
3000CXDHS
F
Protective jack handle sleeve, helps prevent accidental
damage to car body work when pumping the handle.
Made from an EVA material which is oil resistant.
Suitable for all jack handles with 30mm diameter.
Size (L x ØID):
400 x 30mm
Model No:
3003CXQ
3200CXQP
2000LEQ
2500LE
3001LE
Capacity:
3tonne
3.2tonne
2tonne
2.5tonne
3tonne
Minimum Saddle Height:
145mm
145mm
80mm
85mm
95mm
Maximum Saddle Height:
504mm
504mm
375mm
450mm
480mm
Maximum Chassis Height:
163mm
163mm
92mm
155mm
155mm
Length:
690mm
690mm
860mm
600mm
675mm
Weight:
37.2kg
36kg
41kg
34kg
38kg
A
B
C
D
E
B
A
D
C
Rocket Lift
feature brings
lifting arm into contact with
jacking point on average in 5
or less strokes of the handle.
Check product description
for more details.
Super Rocket Lift
feature
brings lifting arm into
contact with jacking point
in 1-2 strokes of the handle.
Check product description
for more details.
C
(685mm)
(80mm)
