Diagnostic Tools
389
Official Suppliers of Autel in the UK
VAG505 SPECIFICATION
Works with all (Petrol 2001 and Diesel 2004 onwards) OBDII / EOBD compliant vehicles and
some models from 1996
Scans for Diagnostic Trouble Codes (DTC) - The cause of the ‘Engine and Transmission
Malfunction Indicator Light (MIL)
Scans for pending DTCs
5HWULHYHV JHQHULF 3 3 3 8 DQG PDQXIDFWXUHU VSHFLÀF 3 3 8 '7&V
Turns off MIL light, clears DTCs and resets monitors
'LVSOD\V '7& GHÀQLWLRQV RQ VFUHHQ
View freeze-frame data
Displays monitor and I/M readiness status (emissions)
Retrieves vehicle information (VIN, CID & CVN)
Supports CAN and other current EOBD Protocols
Supports the new extended sensor list (SAE J1979 - 2007)
Reads live ECU/PCM data stream
Displays live O2 sensor data
Dual graphing function for live data
Read, store and playback live sensor data
Performs ‘modules present’ test
Print out data via PC - Compatibility - Vista, XP, Win7
Update software via the internet - Compatibility - Vista, XP, Win7
Built-in EOBD library lookup
0DQXIDFWXUHU 6SHFLÀF 6RIWZDUH IRU PRVW FRQWURO PRGXOHV
Resets oil service light, service mileage and service intervals (including Long Life)
EPB wind-back for replacing and recalibrating brake pads
Chargeable updates when available
AL619 SPECIFICATION
Works with all (Petrol 2001 and Diesel 2004 onwards) OBDII / EOBD compliant vehicles
Scans for Diagnostic Trouble Codes (DTC) - The cause of the ‘Engine and Transmission’
Malfunction Indicator Light (MIL)
Scans for pending DTCs
5HWULHYHV JHQHULF 3 3 3 8 DQG PDQXIDFWXUHU VSHFLÀF 3 3 8 '7&V
Turns off MIL light, clears DTCs and resets monitors
'LVSOD\V '7& GHÀQLWLRQV RQ VFUHHQ
View freeze-frame data
Displays monitor and I/M readiness status (emissions)
Retrieves vehicle information (VIN, CID & CVN)
Supports CAN and other current EOBD Protocols
Supports the new extended sensor list (SAE J1979 - 2007)
Reads live ECU/PCM data stream
Displays live O2 sensor data
Dual graphing function for live data
Read, store and playback live sensor data
Performs ‘modules present’ test
Print out data via PC - Compatibility - Vista, XP, Win7
Update software via the internet - Compatibility - Vista, XP, Win7
Built-in EOBD library lookup
ABS/Airbag applications: Abarth, Acura, Alfa, Audi, BMW, Bentley, Bugatti, Chrysler, Citroen,
'DFLD )LDW )RUG *0 +RQGD +\XQGDL ,QÀQLWL -DJXDU .LD /DQFLD /DQG 5RYHU /H[XV 0LQL
Maybach, Mazda, Mercedes, Mitsubishi, Nissan, Peugeot, Renault, Scion, Saab, Seat, Skoda,
Smart, Subaru, Suzuki, Toyota, VW, Volvo.
Chargeable updates when available
AL619A SPECIFICATION
Works with all (Petrol 2001 and Diesel 2004
onwards) OBDII / EOBD compliant vehicles
Supports CAN and other current EOBD
Protocols
Scans for Diagnostic Trouble Codes (DTC)
The cause of the ‘Engine and Transmission’
Malfunction Indicator Light (MIL)
Performs bi-directional tests such as cycling
the ABS solenoids, running pump motor and
activating seat belt reminders
Scans for pending DTCs
Reads live ECU/PCM data stream
Retrieves generic (P0, P2, P3 & U10) and
PDQXIDFWXUHU VSHFLÀF 3 3 8 '7&V
Displays live O2 sensor data
Turns off MIL light, clears DTCs and resets monitors
Graphing function for live data
'LVSOD\V '7& GHÀQLWLRQV RQ VFUHHQ YLHZ
freeze-frame data
Read, store and playback live sensor data,
Performs ‘modules present’ test
Displays monitor and I/M readiness status
(emissions)
Print out data via PC
Compatibility - Vista, XP, Win7
Reads live ECU/PCM data stream
Update software via the internet
Compatibility - Vista, XP, Win7
Patented One-Click I/M readiness button
(emissions)
Built-in EOBD library lookup
Retrieves vehicle information
(VIN, CID & CVN)
Supports the new extended sensor list
(SAE J1979 - 2007)
12 months free updates
12 months warranty
No lock out when updates expire
8. WHOHSKRQH VXSSRUW
ABS/Airbag Applications: Abarth, Acura, Alfa, Audi, BMW, Bentley, Bugatti, Chrysler, Citroen, Dacia,
'DHZRR )LDW )RUG *0 +RQGD +\XQGDL ,QÀQLWL ,VX]X -DJXDU .LD /DQFLD /DQG 5RYHU /H[XV 0LQL
Maybach, Mazda, Mercedes, Mitsubishi, Nissan, Peugeot, Porsche, Renault, Scion, Saab, Seat, Skoda,
Smart, Subaru, Suzuki, Toyota, Vauxhall/Opel, Volvo, VW
A
NEW
EOBD Code Reader
Service & Diagnostic Tool - VAG
Model No.
VAG505
A
Combines an EOBD code reader and
OEM level diagnostic tool for most
Audi, Seat, Skoda and VW vehicles
from 1996on. Using Volkswagen
proprietary diagnostic protocol, reads
and clears Diagnostic Trouble Codes
(DTCs) for engine, ABS, airbags,
transmission, radio, climate control,
A/C, steering wheel, immobilizer and
most other vehicle modules. Resets
oil service light, service mileage and
service intervals (including Long Life).
Includes EPB wind-back for replacing
and recalibrating brake pads. Also
reads and clears fault codes. Supports
the new extended sensor list (SAE
J1979 2007). The tool is updateable
via web-based downloads. Supplied
with operating instructions, CD and
USB cable in storage pouch.
Colour
B
NEW
EOBD Code Reader
ABS/Airbag Reset Tool
Model No.
AL619
B
Extremely powerful two-in-one handheld
unit featuring an EOBD code reader
and ABS/Airbag tool. Manufacturer
specific software forABS/Airbag covers
39 vehicle manufacturers. Suitable for
any EOBD compliant vehicle to read
EOBD diagnostic codes (Engine/
Transmission) and enables the cause
of the illuminated engine check light
(MIL) to be established. Includes
all the usual features expected in a
quality EOBD code reader. The tool is
updateable via web-based downloads.
Supplied with operating instructions,
CD and USB cable in storage pouch.
Colour
C
NEW
Colour
EOBD Code Reader - Advanced
ABS/Airbag Reset Tool
Model No.
AL619A
C
Extremely powerful two-in-one handheld
unit featuring an EOBD code reader
and advanced ABS/Airbag tool.
Manufacturer specific software for ABS/
Airbag with extensive vehicle coverage
for more than 40 US, Asian and
European vehicle makers. Performs
bi-directional tests such as cycling the
ABS solenoids, running pump motor
and activating seatbelt reminders.
Suitable for any EOBD compliant
vehicle to read EOBD diagnostic codes
(Engine/Transmission) and enables
the cause of the illuminated engine
check light (MIL) to be established.
Includes all the usual features expected
in a quality EOBD code reader. Free
updates for 12 months. Updateable via
web-based downloads. Supplied with
operating instructions, CD and USB
cable in storage pouch.
Free Vauxhall/Opel update now
available from Autel online.
Visit
for
concise model applications.
Visit
for
concise model applications.
