Circuit Testers
407
B
K
Hybrid Vehicle Circuit Tester 12 & 42V
Model No.
AK4010
K
Suitable for testing 12 and 42V DC circuits with voltage
identification using blue and red LEDs. Pointed probe
tests through wire insulation. Specially designed for
42V hybrid vehicles.
D
Long Probe Heavy-Duty Circuit Tester 6-24V
Model No.
AK4005
D
Suitable for testing 6, 12 and 24V DC electric circuits.
195mm Insulated probe, with pointed tip, tests through
wire insulation. Supplied with 3mtr coiled cable and
insulated crocodile earth clamp.
A
Automotive Pen Probe Digital Meter
Model No.
TA300
A
Features 3-1/2 digit, 10mm LCD display, data-hold,
auto-ranging, over-range protection and indication,
auto-power-off and spotlight. Measures AC and DC
voltages, resistance, capacitance, frequency and
duty cycle and has diode and continuity test functions.
Supplied with crocodile clip, vehicle accessory socket
plug, two probes, probe guard and 1.3mtr cable.
AC Voltage:
0-600V
DC Voltage:
0-600V
Capacitance:
0-100μF
Frequency:
0-10MHz
Duty Cycle:
0.1-99%
Resistance:
0-40M
:
Continuity Test, Audible:
<50
:
Diode Check:
I
Circuit Tester with Polarity Test 6-24V
Model No.
AK4030
I
Probe tool allows continuity and polarity tests to be
carried out quickly and efficiently on 6, 12 and 24V
systems. Positive/negative polarity indicated by red/
green LEDs respectively. Supplied with 1.5mtr cable
and shrouded earth clip.
C
Circuit Tester with LEDs 3-48V
Model No.
AK4051
C
Suitable for testing electrical circuits from 3 to 48V
DC. Integral, spring loaded, pointed probe for testing
through insulation. Twin LEDs indicate live circuit and
polarity. Supplied with 0.9mtr cable and insulated
crocodile earth clamp.
F
Circuit Tester with Test Light 6-24V
Model No.
AK4008
F
Suitable for 6-24V DC circuits. Knurled brass body
with test light. Probe tip is covered with protective
brass screw cap. Tester illuminates when voltage is
present. Supplied with cable and alligator earth clip.
G
Series Type Auto Electric Circuit Tester 6-24V
Model No.
AK402
G
Suitable for testing 6, 12 and 24V DC circuits.
Insulated, pointed probe tests through wire insulation.
Supplied with 1.5mtr cable and crocodile earth clamp.
E
Cordless Circuit Tester 3-28V
Model No.
AK415
E
Suitable for testing DC circuits with voltages between 3
and 28V. No earth clips to get tangled - simply contact
the wire to be tested and touch your finger on bare metal
ground to get a reading. Tester illuminates LED, buzzes
and vibrates on contacting live wire. Computer-safe
for use around delicate engine management systems.
Supplied fitted with 2 x long life N-sized batteries.
H
LCD Electronic Circuit Tester 6-28V
Model No.
AK416
H
Suitable for testing DC circuits with voltages between
6 and 28V. No earth clips to get tangled - simply
contact the wire to be tested and touch your finger
on bare metal ground to get a reading. Liquid crystal
display shows ‘CIRCUIT OK’ and indicates polarity of
circuit contacted i.e. ‘+’ or ‘-’. Computer-safe for use
around sensitive engine management systems.
J
Electric Circuit Tester 6-48V
Model No.
AK407
J
Suitable for 6, 12, 24 and 48V AC and DC circuits. LED
array indicates polarity and voltage range. Supplied
with 850mm cable and crocodile earth clamp.
Integrated Test Light/Voltmeter 3-48V
Model No.
PP5
B
Test light and voltmeter in one tool. LCD meter draws
minute currents making this tool safe to use around
delicate electronic components. With a range of 3-48V
DC, this tool is suitable for motorcycle, car and HGV
applications. Includes interchangeable probes, leads
and clips with Ø4mm banana-type quick couplings.
Contents:
Large Clamp, Crocodile Clip, 65mm Probe,
175mm Probe, Ø4mm Banana-Type Straight Connector
