Multimeters
403
MULTIMETER
SPECIFICATION
MM19
MM20
TM100
TM101
TM102
TM103
MM18
TM105
MM405
AC Voltage
(Accuracy)
200V, 750V
(±2%)
200V, 600V
(±1.2%)
200V, 600V
(±1.2%)
200V, 600V
(±1.2%)
200mV (±1.5%),
2V (±1.2%),
20V, 200V
(±1.5%),
600V, 1000V
(±2%)
400mV (±1.5%),
4V (±1.2%),
40V, 400V
(±1.5%),
600V (±2%)
250V (±1.2%)
200mV (±1.5%),
2V, 20V,
200V (±1.8%),
600V (±2.5%)
DC Voltage
(Accuracy)
200mV,
2000mV, 20V,
200V (±1.5%),
1000V (±1.8%)
200mV (±0.5%),
2V (±0.8%),
20V (±0.8%),
200V (±0.8%),
600V (±0.8%)
0-200mV,
2000mV, 20V
(±0.5%),
200V, 600V
(±0.8%)
0-200mV,
2000mV, 20V
(±0.5%),
200V, 600V
(±0.8%)
0-200mV
(±0.5%),
2V, 20V, 200V
(±1.2%),
600V, 1000V
(±1.5%)
0-400mV
(±0.5%),
4V, 40V,
400V (±1.2%),
600V (±1.5%)
2V, 250V (±1%)
0-200mV
(±0.8%),
2V, 20V,
200V (±1.5%),
600V (±2%)
AC Current
(Accuracy)
200μA (±1.5%),
2000μA, 20mA,
200mA (±1.8%),
10A (±3%)
400μA (±1.5%),
4000μA, 40mA,
400mA (±1.8%),
10A (±3%)
2A, 20A,
200A (±2.5%),
400A (±3%)
0-200A
(±3%)
DC Current
(Accuracy)
200μA, 2000μA,
20mA (±2%),
200mA (±2.2%),
10A (±2%)
2mA,
20mA (±1%),
200mA (±1.2%),
10A (±2%)
0-2000μA,
20mA (±1%),
200mA (±1.2%),
10A (±2%)
0-2000μA,
20mA (±1%),
200mA (±1.2%),
10A (±2%)
200μa (±1%),
2000μa, 20mA,
200mA (±1.5),
10A (±2.5%)
400μa (±1%),
4000μa, 40mA,
400mA (±1.5),
10A (±2.5%)
200mA (±1.2%)
0-200A
(±2.8%)
Resistance
(Accuracy)
200
:
,
2000
:
, 20k
:
,
200k
:
(±1.8%),
2000k
:
(±2%)
200
:
,
2k
:
, 20k
:
,
200k
:
(±0.8%),
2M
:
(±1.2%)
0-200
:
, 2000
:
,
20k
:
, 200k
:
(±0.8%),
2000k
:
(±1%)
0-200
:
, 2000
:
,
20k
:
, 200k
:
(±0.8%),
2000k
:
(±1%)
0-200
:
(±1.2%),
2k
:
(±1%),
20k
:
, 200k
:
,
2M
:
(±1.2%),
20M
:
(±2%)
0-400
:
(±1.2%),
4k
:
(±1%),
40k
:
, 400k
:
,
4M
:
(±1.2%),
40M
:
(±2%)
2k
:
, 20k
:
,
200k
:
, 2000k
:
(±1.2%)
0-200
:
(±1%),
2k
:
, 20k
:
,
200k
:
(±1.5%),
2M
:
(±2.5%),
20M
:
(±3.5%)
Capacitance
(Accuracy)
4nF,
40nF (±5%),
400nF,
4μF,
40μF (±3%),
200μF (±5%)
Temperature
(Accuracy)
-40°C-1000°C,
(±1% up to
400°C),
(±2% over
400°C)
-50ºC-1000ºC
(±3%),
-58 to 1832ºF
-20ºC to
760ºC (±3%),
-4 to 1400ºF
(±5%)
Frequency
(Accuracy)
9.999Hz
to
9.999MHz
40-51,
51-510Hz,
0.51-1kHz
(all ±1.2%)
Duty Cycle
0.1%~99.9%
(±1.2%)
Continuity Audible
Diode Test
Transistor Test
Hi-Impact
Rubber Case
Digits x Height
3.5 x 22mm 6 x 12mm 3.5 x 27mm 3.5 x 27mm 3.5 x 14mm 4 x 14mm 5 x 11mm 3.5 x 14mm 4 x 11mm
Low Battery
Indicator
Batteries (Supplied)
1 x 9V
1 x 9V
1 x 9V
1 x 9V
1 x 9V
1 x 9V
2 x 1.5V
1 x 9V
2 x 1.5V
Information
-
Integral
Stand
Battery Test
1.5V, 9V (±1%)
Battery Test
1.5V, 9V (±1%)
& Non Contact
Voltage
Detection
(NCVD)
Data-Hold
& Auto
Power Off
Data-Hold
& Auto
Power Off
-
Data-Hold
& Auto
Power Off
Voltage
Detection:
100~600VAC,
Soft Padded
Carry-Case
Size
(L x W x D)
130 x 70
x 14mm
140 x 70
x 35mm
145 x 68
x 35mm
145 x 68
x 35mm
150 x 70
x 48mm
150 x 70
x 48mm
114 x 56
x 23mm
197 x 70
x 40mm
155 x 66
x 31mm
Weight
240g
260g
260g
260g
255g
255g
101g
183g
160g
Conformity
IEC 1010
IEC 1010
EN 61010-1
EN 61010-1
EN 61010-1
EN 61010-1
EN 61010-1
EN 61010-1
IEC 1010
