Brake & Clutch Service Tools
463
A
Brake & Clutch Bleeding System
Model No.
VS820
A
One-man brake and clutch bleeding the professional
way. Bleeding requires no external power source -
simply fill and pump. Reservoir holds 2.5ltr of hydraulic
fluid - flush the entire system with one fill without the
risk of running the reservoir dry. Pressure range
makes unit suitable for use with ABS systems. Fitted
with Ø42mm cap with 90° angled connector which is
suitable for most European models.
For other applications order optional Brake Reservoir
Cap 42mm Straight Connector - Model No.
VS820SA
or Universal Adaptor - Model No.
VS820UA
.
Tank Capacity:
2.5ltr
C
Brake Reservoir Cap 42mm
Straight Connector
Model No.
VS820SA
C
For use in conjunction with Model No’s. VS820 &
VS821 Brake & Clutch Bleeding Systems. Brake
reservoir cap Ø42mm with straight coupling.
D
Brake & Clutch Bleeder Universal Adaptor
Model No.
VS820UA
D
Universal reservoir cap for Model No’s. VS820 &
VS821 Brake & Clutch Bleeding Systems. Supplied
with quick connect.
Pneumatic Brake & Clutch Bleeder
Model No.
VS821
B
Professional one-man brake and clutch bleeder that
uses air from the vehicle tyre. Reservoir holds 1.5ltr
of hydraulic fluid - flush the entire system with one fill
without the risk of running the reservoir dry. Maximum
pressure of 30psi makes the unit suitable with ABS
systems. Features a fluid shut-off valve to prevent
accidental spillage and air pressure release valve.
Fitted with Ø42mm cap with 90° angled connector
which is suitable for most European models.
For other applications order optional Brake Reservoir
Cap 42mm Straight Connector - Model No.
VS820SA
or Universal Adaptor - Model No.
VS820UA
.
Maximum Pressure:
30psi
Tank Capacity:
1.5ltr
Brake Bleeding Bottle 500ml
Model No.
VS0212
E
Composite collection bottle with wide base for added
stability. Features a one way valve to reduce air
re-entering the system, clear hose to evaluate the
condition of the bled fluid and presence of air, air vent
located in the lid and drain cap for simple emptying of
old brake fluid. Includes two hanging hooks.
Tank Capacity:
500ml
Hose Length:
1mtr
F
Gravity Brake Bleeder Kit
Model No.
VS0209
F
Ingenious patented design maintains the fluid level
in the vehicle’s brake or clutch fluid reservoir during
the bleeding process. No electricity or compressor
required, ideal for use on a vehicle lift. Uses the
standard 500ml brake fluid bottle in which fluid is
supplied, reducing the possibility of contamination.
Fast, simple to use and features on/off flow valve.
Information
Alternative Reservoir Caps for Model No’s
VS820 and VS821 are available as spare
parts from Model No’s VS0204 and VS0207
on page 464.
NEW
B
NEW
E
G
Brake Piston Wind Back Tool Kit 5pc
Model No.
VS0211
G
Innovative dual purpose tool designed to push and
wind back brake callipers. Fast and simple, one
handed use. Lightweight and durable materials enable
the tool to work on most common calliper designs.
Suitable for use on either left or right-handed wind
back callipers. Supplied with four common adaptors
but compatible with all 2-pin magnetic adaptors in the
Sealey range, making the tool truly versatile.
