464
Brake & Clutch Service Tools
A
Pneumatic Pressure Bleeder Kit
Model No.
VS0204
A
One-man pressure brake and clutch bleeding system suitable for the professional
workshop. Low pressure tank (20-40psi) can be pre-charged with compressed
air, making the unit fully portable. Large reservoir means reduced risk of running
the system dry during bleeding process or complete fluid change. Suitable for
use on ABS systems. Features a long delivery hose for operation with a low level
ramp and long reach handle for easy mobility. Supplied with a range of European,
Japanese and US vehicle adaptors.
Air Supply:
20-40psi
Air Consumption:
4.5cfm
Tank Capacity:
5ltr
Inlet Size:
1/4"BSP
Hose Length:
3.7mtr
B
Brake & Clutch Pressure Bleeder Kit 12V
Model No.
VS0207
B
Powered by the vehicle’s own 12V battery. Allows single-handed bleeding of the
vehicle’s brake or clutch system and unit is fitted with a long, high pressure hose.
Bleed pressure is closely controlled up to 2.5bar - suitable for most vehicles (even
those with ABS). Unit fitted with auto-shut-off device to prevent the system running
dry and is supplied with a variety of European, Japanese and US vehicle adaptors,
bleed bottle and fluid extractor.
Maximum Pressure:
2.5bar
Power Supply:
12V
Cable Length:
4mtr
Hose Length:
5mtr
Tank Capacity:
2ltr
Machine Weight:
7.9kg
D
Brake Fluid Bleeder 12V
Model No.
VS0208
C
Bleeds brakes first time, every time (one-man bleeding
operation). Powered by the vehicle’s 12V battery and
maintains system pressure using an electric pump to
drive clean hydraulic fluid through a long high pressure
hose to the reservoir. Variable pressure delivery
means that vehicles with specific requirements may be
bled safely. Pressure can be adjusted to a maximum
pressure of 2bar which is suitable for most vehicles.
Supplied with a 42mm semi-universal reservoir
cap which will fit a large percentage of European
manufactured vehicles from 1997 onwards.
Maximum Pressure:
2bar
Power Supply:
12V
Cable Length:
2.5mtr
Hose Length:
2.9mtr
Tank Capacity:
5ltr
Machine Weight:
6.5kg
Hydraulic Brake & Clutch Bleeding System
Model No.
VS0206
D
One-man brake and clutch bleeding made easy. Ideal
for use on the vehicle lift as unit maintains system
pressure using electric pump to drive clean hydraulic
fluid through a long high pressure hose to the reservoir
- enables quick, ‘walk-around’ brake bleeding. High
pressure system feeds fluid at up to 5.8bar making it
particularly suitable for modern brake systems found
on many vehicles including Audi, BMW and Mercedes.
Features thermal control of pump for long and reliable
pump life. Includes Ø42mm reservoir adaptor and
accepts all manner of brake fluid canisters up to 10ltr
depending on their shape.
Maximum Pressure:
5.8bar
Power Supply:
230V
Machine Weight:
10kg
Model No. VS0206 is fitted with a thermal cut
out which will operate at around 15 minutes of
continuous use, so will not be suitable for vehicle
systems that require prolonged diagnostics to
bleed the braking system. The thermal cut out is
a safety feature designed to protect and prolong
the life of the pump.
Brake & Fuel Pipe Inspection Tool
Model No.
VS0210
E
Specially designed for the removal of corrosion from
brake and fuel pipes for fast and thorough inspection.
Features 12 cleaning edges for different sizes and
types of pipes. Includes curved cleaning edges for
hard-to-reach areas. MOT Compliant tool.
Applications:
3.5mm (Citroen), 4, 4.75mm, 3/16" Pipes
For our full range of Vacuum Testing Kits,
see page 382.
C
VACUUM TESTER &
BRAKE BLEEDING KITS
E
