492
Hub Tools
A
Slide Hammer/Hub Puller Set
Model No.
VS3700
A
Designed for the removal of stubborn four and five stud
hubs and brake drums on cars and light commercial
vehicles. Includes 4.3kg slide hammer, manual force
screw and two sizes of stud.
Stud Sizes:
M12 x 1.5, M14 x 1.5mm
Slide Hammer Travel:
340mm
Hub Plate Thickness:
20mm
B
Hub Puller Set
Model No.
PS994
B
Specially designed to fit four and five stud hubs, fitted
to cars and light commercial vehicles. Unique design
allows for the leg angle to change as the hub is being
pulled. Force screw handle included and supplied in
carry-case.
Maximum Vehicle Stud Size:
17mm
Maximum Leg Spread:
220mm
Reach:
140mm
C
Hydraulic Hub Puller Set
Model No.
PS993
C
Chromed, heat treated S45C steel puller yoke with
hydraulic ram. Suitable for four and five stud hubs.
Hydraulic ram provides additional power to extract the
most stubborn hubs. Supplied in storage case.
D
CVJ Thread Chaser 8pc
Model No.
VS715
D
A must have tool for every workshop. Repairs light
damage to CV joint threads. Set contains sizes to fit
the most common types of vehicle. Must be used with
a light oil to lubricate thread. Supplied in storage case.
Contents:
M20 x 1.25, M20 x 1.5, M22 x 1,
M22 x 1.5, M24 x 1.5, M24 x 2mm, 3/4" x 20 UNEF,
13/16" x 20 UNEF
E
Hub Puller
Model No.
AK383
E
Steel body with thrust bolt. Suitable for hubs with
four stud fixings and stud centres between 110 and
115mm.
F
Universal Hub Puller
Model No.
AK713
F
Ductile steel electrodeposition finished body with
thrust bolt and tommy bar. Suitable for four and five
stud hubs. Use with a 1/2"Sq drive ratchet wrench or
with tommy bar supplied.
Bearing Race & Seal Driver Set 10pc - Steel
Model No.
VS7031
G
Set of nine heavy-duty steel bearing and seal drivers.
Suitable for straight installation of bearing race without
damage to the bearing or axle housing. Fits most
popular bearing race sizes.
Driver Sizes Ø:
39.5, 44, 50, 59, 63, 64.5, 72,
76, 81mm
H
Seal Driver Set 18pc
Model No.
VS704
H
Set of assorted seal drivers suitable for installation of
seals without damage. Includes three hooded drivers
for seals with dust shields.
Driver Sizes Ø:
Flat; 33, 38, 41, 43, 49, 52, 54,
61.5, 65, 69.5, 76, 82, 85mm, Hooded; 62, 69.5,
88.5mm
I
Bearing Race & Seal Driver Set 10pc - Aluminium
Model No.
VS703
I
Set of nine aluminium bearing and seal drivers.
Suitable for straight installation of bearing race without
damage to the bearing or axle housing. Fits most
popular bearing race sizes.
Driver Sizes Ø:
39.5, 44, 50, 59, 63, 64.5, 72,
76, 81mm
G
