Suspension Tools
501
H
A
Coil Spring Compressor Set 2pc
Model No.
AK3841
A
Carbon steel, hardened lead screws and cast jaws.
Wrap over coil claws for extra safety. Suitable for use
where space under wheel arch is limited.
Drive:
1/2"Sq
Maximum Jaw Opening:
230mm
B
Coil Spring Compressor Set 3pc
Model No.
AK384
B
Carbon steel, hardened lead screws and cast jaws
with safety hooks to prevent accidental release of
spring under compression.
Drive:
1/2"Sq
Maximum Jaw Opening:
250mm
C
Coil Spring Compressor
Model No.
AK3842
C
Heavy-duty Chrome Vanadium construction.
Long-reach arms compress a higher proportion of
the coil spring. Allows even and safe compression of
spring prior to installation.
Drive:
19mm Hex
Maximum Jaw Opening:
350mm
D
Coil Spring Compressor Set 2pc
Model No.
AK3843
D
High security coil spring compressor with 1200kg
maximum capacity per pair, featuring adjustable
safety bar for additional security. Compressors have
lower safety jaws for ultimate peace of mind. Use
19mm hex socket or spanner.
Drive:
19mm Hex
Maximum Jaw Opening:
290mm
Maximum Capacity per Pair:
1200kg
E
Heavy-Duty Coil Spring Compressor Set 2pc
Model No.
AK3845
E
Heavy-duty coil spring compressor with hardened
steel body and force screw. Ensures smooth
compression of spring.
Drive:
19mm Hex
Maximum Jaw Opening:
280mm
Maximum Capacity per Pair:
1000kg
F
Strut Nut Socket - Audi, VW
Model No.
SX028
F
Suitable for the removal and installation of top shock
retaining nut. Location pegs fit into slots cut in the
retaining ring and allow hex key access through the
centre for release/adjustment of the shock. Use with
22mm spanner.
Applications:
Most Audi & VW front wheel drive vehicles
G
Strut Nut Tool Set 3pc - Audi, VW
Model No.
SX033
G
Suitable for the removal and installation of strut nuts
on McPherson struts fitted to Audi and VW vehicles.
Sizes:
10.5, 12.5, 14.5mm
Strut Leg Pry Socket 2pc 1/2"Sq Drive
Model No.
SX034
H
Reduces risk of damage to hub casting associated
with using hammers and chisels to free the strut leg.
Suitable for removal and installation of legs on most
Audi, Ford, Peugeot, Renault, Seat, Skoda and VW.
Sizes:
7 x 5mm, 8.2 x 5.5mm
E
IMPORTANT SAFETY
INFORMATION
$OZD\V HQVXUH FRPSUHVVRU MDZV DUH VHFXUHO\
engaged onto the spring.
/XEULFDWH WKH WKUHDGV EHIRUH XVH
'R QRW XVH LPSDFW WRROV ZLWK WKH VSULQJ
compressors.
'R QRW DOORZ WKH FRLOV RI WKH VSULQJ WR WRXFK
together.
)ROORZ PDQXIDFWXUHU©V VDIHW\ JXLGHOLQHV
