Specialised Bit Sets
509
A
Security TRX-TS* Socket Bit Set 7pc
1/4"Sq Drive
Model No.
SX106
A
Chrome Vanadium steel sockets and bits. Knurled ring
on sockets to assist gripping with oily fingers. 5-Spline
security TRX-TS* bits suitable for a range of fuel
injection applications. Supplied on socket rail.
Drive:
1/4"Sq
Contents:
TS10H, TS15H, TS20H, TS25H, TS27H,
TS30H, TS40H
B
Ribe Socket Bit M9 x 100mm 1/2"Sq Drive
Model No.
SX110
B
1/2"Sq Drive satin finished Chrome Vanadium steel
socket with knurled ring and S2 steel bit. Suitable for
VW Passat cylinder head bolts.
C
Head Bolt Socket Bit Set 10pc 1/2"Sq Drive
Model No.
AK5538
C
Head bolt removal tools with long reach suitable for
modern engines. Nine drop-forged Chrome Vanadium
steel sockets with S2 steel male bits, and one single
piece Chrome Vanadium TRX-Star* deep socket.
Sockets heat treated and chrome plated with satin
finish for resistance to corrosion. Knurled ring on
sockets to assist gripping with oily fingers. Suitable for
BMW, Fiat, Ford, Mazda, Mercedes, Nissan, Renault,
Rover and VAG vehicles. Supplied in storage case.
Contents:
Length 60mm:
M12 (Ribe), T70 (TRX-Star*)
Length 97mm:
M14 (Security Spline)
Length 100mm:
M9 (Ribe)
Length 117mm:
M12 (Ribe)
Length 150mm:
E12 (TRX-Star* Socket), T60H
(SecurityTRX-Star*),M10(Spline),10mm(Hex),M10(Ribe)
D
Spline Cylinder Head Bolt Socket Bit
M10 x 140mm 1/2"Sq Drive
Model No.
AK5533
D
Head bolt socket bit suitable for Ford, Mercedes vans,
VAG and Vauxhall/Opel. 140mm S2 Steel shaft.
E
Spline Bit Set M14 - Pack of 2
Model No.
AK5532
E
Manufactured from Chrome Vanadium. Specially
designed for use on Ford bell housings. Use with
10mm spanner to access restricted areas.
Length:
30mm
F
Spline Cylinder Head Bolt Socket Bit
M14 x 100mm 1/2"Sq Drive
Model No.
AK5531
F
1/2"Sq Drive satin finish Chrome Vanadium steel
socket with knurled ring and S2 steel shaft. Suitable
for VW Type 4 Transporter bottom wishbone bolts.
G
Security Spline Socket Bit M16 1/2"Sq Drive
Model No.
SX107
G
1/2"Sq Drive Chrome Vanadium steel socket with
knurled ring and S2 steel bit. Suitable for gearbox
drain plugs on Audi; A3, A4, A6, VW; Golf IV and LT.
H
Security TRX-Star* Socket Bit
T70 x 105mm 1/2"Sq Drive
Model No.
SX108
H
1/2"Sq Drive Chrome Vanadium steel socket with
knurled ring and S2 steel bit. Suitable for gearbox
drain plugs on VAG vehicles.
I
Security TRX-TS* Key Set 7pc - Short
Model No.
AK6178
I
5-Sided Chrome Vanadium steel key set suitable for
a range of ECU, Air Conditioning and Fuel Injection
Pump applications. Supplied in easy-access case with
hanging tag for safe storage and quick key selection.
Contents:
TS10H, TS15H, TS20H, TS25H, TS27H,
TS30H, TS40H
Lengths:
50-95mm
ECU Applications:
Peugeot, Renault, Rover
Air Conditioning Applications:
Mercedes
Injection Pumps Applications:
Wide Range of
Diesel Vehicles
J
Spline Socket Bits - Extra-Long
800mm 1/2"Sq Dive
Model No.
SEE BELOW
J
Save valuable time and loosen drive shaft screws from
the outside. Suitable for VAG vehicles. Hardened and
tempered Chrome Vanadium steel socket. Chrome
plated with satin finish. Knurled ring on socket to assist
gripping with oily fingers. S2 Steel spline bit extension
with phosphate coating.
Model No:
Size:
Drive:
Length:
AK5535
M8
1/2"Sq
800mm
AK5536
M10
1/2"Sq
800mm
K
Offset Ratchet Wrenches
Model No.
SEE BELOW
K
Ergonomically designed, Chrome Vanadium steel,
reversible ratchet wrenches with offset handle and
anti-slip grip. Hardened and tempered with polished
chrome finish. Features ultra-smooth 72-tooth ratchet
action allowing ratcheting in increments of 5°, for
ease of use in restricted areas. Quick release with
spring-ball socket retention and flip reverse.
Model No: Drive: Ratchet: Length:
Repair Kit:
AK966
1/4"Sq 72-Tooth 155mm
AK966.V3.RK
AK967
3/8"Sq 72-Tooth 198mm
AK967.V3.RK
AK968
1/2"Sq 72-Tooth 255mm
AK968.V3.RK
