Sealey Catalogue

470 / 1140

470 Battery & Alternator Testers
sealey tools @sealeytools sealey tools
A B
12V
6V
C
12V
6V
24V
SIMPLE TO USE
 Connect to battery - tester reads
battery voltage.
 Select battery type.
 Input battery amperage.
 Press
enter.
 Battery condition is displayed
in full*.
*BT2101, BT2001 & BT2002
12V 6V
F
12V
A Digital Battery Tester 12V
Model No. BT2101
Fast and accurate assessment of battery condition,
even with the battery partially discharged. No heat,
no sparks and no misdiagnosis. Tests battery in
accordance with rated output based on SAE, DIN or
ENC2 criteria and displays results on LCD screen.
Diagnose battery faults at the trade counter, service
reception or in workshop with confidence. Rugged
construction. Supplied with instruction manual.
Rated Battery Voltage: 12V
Rating Systems: SAE, DIN, ENC2
Test Range: 200-1200 CCA* (SAE), 9-15V
Minimum Power Requirement: 9V
*CCA - Cold Cranking Amps
C Digital Battery & Alternator Tester
6/12/24V
Model No. BT2002
Professional diagnosis of battery and alternator faults.
Test battery condition with as little as 1V of residual
charge. No heat, no sparks and no misdiagnosis.
Checks condition of starter - no complicated
connections or interpretation required. Analyse the
vehicle’s charging system at rest and under load to
determine condition of alternator. Connect and follow
the prompts on the LCD screen for straightforward
answers. Incorporates simple voltmeter for voltage
tests and additional system diagnostics. Rugged
construction with protective cover. Supplied with full
instruction manual.
Rated Battery Voltage: 6/12V
Charging System Capability: 6/12/24V**
Rating Systems: SAE, DIN, EN, IEC
Test Range: 40-2100 CCA* EN
40-2000 CCA* SAE
30-1500 CCA* IEC
25-1300 CCA* DIN
Minimum Power Requirement: 1V
*CCA - Cold Cranking Amps. ** 24V Alternator Test only
D
D Digital Battery Tester with Printer
6/12V
Model No. BT2013
Fast, accurate diagnosis and recording of battery
faults. Tests battery condition and charge level. LCD
screen shows easy-to-follow test prompts and results.
Integral printer will produce hard-copy results for
your own or customer’s records. Suitable for Regular
Liquid, AGM Flat Plate, AGM Spiral and Gel batteries.
Supplied with carry-case, two printer rolls and
instruction manual.
Rated Battery Voltage: 6/12V
Rating Systems: DIN, EN, IEC, JIS, SAE
Test Ranges: 25-1300 CCA* DIN
40-2100 CCA* EN
30-1500 CCA* IEC
40-2000 CCA* SAE
By Battery Type JIS
Replacement Printer Rolls: (Pack of 2) BT2003.V2-01
*CCA - Cold Cranking Amps
12V
6V
24V
B Digital Battery Tester 6/12V
Model No. BT2001
Fast and accurate assessment of battery condition,
even with the battery partially discharged. No heat,
no sparks and no misdiagnosis. Tests battery in
accordance with rated output based on DIN, ENC1,
ENC2, IEC, JIS or SAE criteria and displays results
on LCD screen. Diagnose battery faults at the trade
counter, service reception or in workshop with
confidence. Rugged construction with protective
cover. Supplied with full instruction manual.
Rated Battery Voltage: 6/12V
Rating Systems: DIN, ENC1, ENC2, IEC, JIS, SAE
Test Range: 40-2100 CCA* EN
40-2000 CCA* SAE
30-1500 CCA* IEC
25-1300 CCA* DIN
Minimum Power Requirement: 1V
*CCA - Cold Cranking Amps
E
E Digital Battery & Alternator Tester
with Printer
Model No. BT2003
Professional diagnosis of battery and alternator
faults with the added facility to print the results. Test
battery condition with as little as 1V of residual charge.
No heat, no sparks and no misdiagnosis. Checks
condition of alternator, no complicated connections or
interpretation required. Analyse the charging system
at rest and under load to determine condition of the
alternator. Connect and follow the prompts on the
2-line/16 character LCD screen for straightforward
answers. Incorporates simple voltmeter for voltage
tests and additional system diagnostics. Rugged
construction. Supplied in carry-case with batteries, two
rolls of printing paper and instruction manual.
Rated Battery Voltage: 6/12V
Charging System Capability: 12/24V**
Rating Systems: DIN, EN, IEC, JIS, SAE
Test Ranges: 40-2100 CCA* EN
40-2000 CCA* SAE
30-1500 CCA* IEC
25-1300 CCA* DIN
By Battery Type JIS
Minimum Power Requirement: 1V
Replacement Printer Rolls: (Pack of 2) BT2003.V2-01
*CCA - Cold Cranking Amps. **24V Alternator Test only
F Printing Rolls for Battery Testers
Model No. BT2003.V2-01
Suitable for Model No’s BT2003, BT2013 and other
leading brands of battery tester.
