Infrared & Ceramic Heaters
A
Infrared Heater 1500/3000W 230V
Model No.
IRS153
A
Powder coated metal construction with tilting head
giving directional heat control. Fitted with two quartz
infrared elements and chemically polished reflectors
for maximum heat emission. Controllable power
output by rocker switches on the rear of the head
assembly. Stand features easy-rolling castors with
a locking castor fitted to the rear. Suitable for a wide
range of heating including restorative applications.
Supplied with cable and BS/ASTA approved plug.
Maximum Power:
3000W
Minimum Power:
1500W
Supply:
230V - 13A
Dimensions (W x D x H):
600 x 620 x 815mm
B
A
B
Infrared Cabinet Heater 1500/3000W 230V
Model No.
IRC153
B
Powder coated metal cabinet with two quartz infrared
elements and chemically polished reflectors for
maximum heat emission. Controllable power output
by rocker switches on the side of the cabinet. Features
easy-rolling castors with two locking castors fitted to
the rear. Suitable for a wide range of heating including
restorative applications. Supplied with cable and
BS/ASTA approved plug.
Maximum Power:
3000W
Minimum Power:
1500W
Supply:
230V - 13A
Dimensions (W x D x H):
560 x 490 x 885mm
C
D
C D
Model No. SEEBELOW
Ceramic Heaters
1400/2800W 230V
Powder coated metal construction with
two ceramic heating elements providing
instant heat when required. Ideal for
workshops and garages. Features
chemically polished reflectors which
provide maximum heat emission.
Controllable power output with rocker
switches on the side of the unit.
Model No. CH2800 fitted with sturdy
frame and carry handle, Model No.
CH2800S supplied with adjustable
height tripod. Both supplied with cable
and BS 1363 approved plug.
E
F
Model No:
CH2800
CH2800S
Maximum Power:
2800W
2800W
Minimum Power:
1400W
1400W
Supply:
230V - 13A
230V - 13A
Dimensions - Heater (W x D x H):
360 x 370 x 555mm
360 x 370 x 555mm
Min./Max. Height:
-
555/1560mm
Weight:
5.52kg
8.14kg
Model No:
CH28110V
CH28110VS
Maximum Power:
2800W
2800W
Minimum Power:
1400W
1400W
Supply:
110V
110V
Dimensions - Heater (W x D x H):
360 x 370 x 555mm
360 x 370 x 555mm
Min./Max. Height:
-
555/1560mm
Weight:
5.68kg
8.3kg
Ceramic Heaters
1400/2800W 110V
Powder coated metal construction with
two ceramic heating elements providing
instant heat when required. Ideal for
workshops and garages. Features
chemically polished reflectors which
provide maximum heat emission.
Controllable power output with rocker
switches on the side of the unit.
Model No. CH28110V fitted with sturdy
frame and carry handle, Model No.
CH28110VS supplied with adjustable
height tripod. Both supplied with 2mtr
cable fitted with 32Amp/110V plug.
E F
Model No. SEE BELOW
E
C
F
D
