556
Industrial Fans
A
Industrial High Velocity Floor Fan 18" 230V
Model No.
HVF18
A
High velocity fans suitable for movement of huge volumes of air. Carefully
balanced and fully guarded blades provide quiet and safe operation.
Three-speed power selection and cradle stand allow precise control of airflow to
exactly where it is needed. Fitted with BS approved plug. Suitable for use in industrial,
commercial, agricultural, automotive workshop and showroom applications.
,QGXVWULDO +LJK 9HORFLW\ )ORRU )DQ Ə 9
Model No.
HVF20
B
High velocity fan suitable for movement of huge volumes of air. Features
three-speed settings for choice of airflow and tilting blade cradle. Fully guarded
blades with large diameter base for safety and added stability. Mains cable storage
keeps it tidy when not in use. Suitable for industrial, commercial, agricultural,
workshop and showroom applications.
Industrial High Velocity Oscillating
Pedestal Fan 30" 230V
Model No.
HVSF30
E
Suitable for movement of huge volumes of air. Fully
guarded blades provide quiet and safe operation.
Three-speed power selection, spring-assisted,
height-adjustable stand and switchable head
oscillation allow precise control of airflow. Suitable for
use in industrial, commercial, agricultural, automotive
workshop and showroom applications.
,QGXVWULDO+LJK9HORFLW\3HGHVWDO)DQ Ə 9
Model No.
HVF20P
C
High velocity fan suitable for movement of huge
volumes of air. Features three-speed settings for
choice of airflow, tilting blade cradle through 135°
angle and height-adjustable stand. Fully guarded
blades with large diameter base for safety and added
stability. Mains cable storage keeps it tidy when not in
use. Suitable for industrial, commercial, agricultural,
workshop and showroom applications.
Industrial High Velocity Oscillating
3HGHVWDO )DQ Ə 9
Model No.
HVF20PO
D
High velocity fan suitable for movement of huge
volumes of air. Features three-speed settings for
choice of airflow, height-adjustable stand, tilting blade
cradle and oscillation. Fully guarded blades with large
diameter base for safety and added stability. Suitable
for industrial, commercial, agricultural, workshop and
showroom applications.
E
Model No:
HVF18
HVF20
HVF20P
HVF20PO
HVSF30
Fan Diameter:
450mm(18")
550mm(20”)
550mm(20")
550mm(20")
760mm(30")
Oscillation:
Speeds:
3
3
3
3
3
Speed Range:
900-1250rpm
1100-1360rpm
900-1300rpm
1060-1340rpm
740-920rpm
Maximum Airflow:
100mtr³/min(3500cfm)
110mtr³/min(3900cfm)
120mtr³/min(4200cfm)
110mtr³/min(3900cfm)
227mtr³/min(8013cfm)
Adjustable Height:
n/a
n/a
1100-1330mm
1080-1410mm
1610-2030mm
Power:
120W
110W
160W
115W
170W
Supply:
230V
230V
230V
230V
230V
Current:
0.6A
0.5A
1.1A
0.5A
1.35A
C
B
D
C
A
B
D
E
NEW
NEW
NEW
Model No. HVSF30 is
supplied with pull cord
speedandon/offselection
plus push/pull switch for
oscillation of head.
