Industrial Fan Heaters
549
F
A
B
C
D
E
C F
Model No.
SEE BELOW
A
E
F
C
D
A B
Model No.
SEE BELOW
Industrial Fan Heaters 1ph
Electric fan heaters for industrial applications. Model
No. EH2001 features one heat setting, Model No.
EH3001 features two heat settings. Both units have
thermostat control and fan only options. A totally dry
heat with no condensation, no gas, no fumes and no
smell. Ideal for workshops, garages etc. Model No.
EH2001 supplied with power cable and 3-pin plug.
Model No. EH3001 supplied with power cable.
B
Industrial Fan Heaters 3ph
Electric fan heaters for industrial applications. Model
No’s EH5001, EH9001 and EH30001 feature two heat
settings and fan only option. Model No. EH15001
features three heat settings and adjustable thermostat
control with fan only option. Auto cooling system to
prevent unit from overheating during use. A totally dry
heat with no condensation, no gas, no fumes and no
smell. Ideal for workshops, garages etc. Model No’s
EH5001 and EH9001 supplied with three phase power
cable and plug. Model No’s EH15001 and EH30001
supplied with three phase chassis mounted 5-pin
connector (extension cable required).
IMPORTANT NOTE
ModelNo’sEH5001,EH9001
and EH15001 and EH30001
require a 3ph supply.
Please ensure installation is
carried out by a competent
electrician.
Model No:
EH2001
EH3001
EH5001
EH9001
EH15001
EH30001
Maximum Power:
2000W
3000W
5000W
9000W
15000W
30000W
Heat Settings:
2000W
1500/3000W
2500/5000W
4500/9000W 5000/10000/15000W
15000/30000W
Supply:
230V - 13A
230V - 16A
415V/3ph - 16A
415V/3ph - 16A
415V/3ph - 32A
415V/3ph - 63A
Dimensions (W x D x H):
215 x 230 x 280mm 315 x 330 x 400mm 315 x 330 x 400mm 350 x 405 x 460mm 495 x 520 x 860mm 645 x 565 x 860mm
EH5001, EH9001 and EH30001 feature two heat
settings, EH15001 features three. All units have a
variable thermostat control and fan only option.
